Vertical Machining Center; 30" x
16" x 20" work envelope: 12,000
RPM direct drive spindle: 4- Axis
high speed machine option; Used
mostly for our aluminum jobs.
Vertical Machining Center: 20” x
16” x 20” work envelope: 7,500
RPM with gear box: 4 - Axis: Used
mostly for coting our high nickel
parts.
HAAS DT1
Production:
Inspection:
Brown & Sharpe CMM
HAAS Super VF-2
HAAS VF2
HAAS VF1
Gage Master Series 20
Vertical Machining Center: 20” x 16”
x 15” work envelope: 15,000 RPM
Direct Drive: 3 - Axis: Rehnishaw
Probe System: We utilize this
machine when high RPM’s and
accuracy are required. Typically
plastic material or when extremely
small diameter tooling is required.
Gang tool for fast tool change. 15
horse power. 6000 rpm. Used for
our smaller turning jobs.
UMP360 Control System: Aluminum
ultra-rigid frame and patented
Tricision and Slant Bridge design:
Nominal Temperature 20 °C (68 °F):
Allowable Temperature Range: 18 -
22 °C (64.4 - 71.6 °F): Extended
Temperature Range: 16 - 26 °C
(60.8 - 78.8 °F): Hexagon
Metrology tests and evaluates
Global Silver Edition CMM products
using the ASME B89 and ISO
10360 standards
Super Kia Turn 15 LMS
Fanuc 0iTB control. Main and sub spindle.
Full C-axis on main, 5 deg index on sub.
Polar coordinate interpolation (simulates y-
axis). Live tooling.
Unique lens focusing system
allows for a fixed distance
between the lamphouse and part
being inspected; standard
electronic digital angle
measurement eliminates operator
error in reading old fashion vernier
type scale. Features floating zero
reset and absolute/incremental
registers
Vertical Machining Center: 30” x
16” x 20” work envelope: 7,500
RPM with gear box: 4 - Axis: used
mostly for high- nickel parts.
